Features of 5000 Liters 4x2 Asphaltum Road Repairing Vehicle
1. Hydraulic drive, reliable, safe and no noise;
2. Latest fan-shaped nozzle, three overlapping design;
3. In the cab equipped with comprehensive controller, real-time monitoring the asphalt temperature and asphalt pumping speed;
4. Asphalt pumping speed manual adjustable;
5. Efficient heat insulated asphalt tank;
6. Automatic Italian Riello burners;
7. High power rear lights for night operation;
Parameter of 5000 Liters 4x2 Asphaltum Road Repairing Vehicle
|
Main technical parameters
|
Name
|
asphalt truck
|
Outline size(mm)
|
7330x2300x2750
|
|
Gross weight(kg)
|
9750
|
|
Engine model
|
CY4102-E3C
|
Loading weight(kg)
|
3950
|
|
Emission/ ( ml/Kw)
|
3856ml/100kw, 136Hp
|
Curb weight(kg)
|
5600
|
|
Engine type
|
Diesel, 4 Cylinders, Direct line, Turbocharge and water cooling
|
|
Fuel type
|
diesel
|
Wheelbase(mm)
|
3800
|
|
Max speed(km/h)
|
90
|
Tire model / number
|
8.25-20 7 unit
|
|
Operation control system
|
Electrically hydraulic
|
Transmission
|
5 speed
|
|
Traction system
|
4x2
|
Electric System
|
24v
|
|
Approaching angle(°)
|
24
|
Front / rear track(mm)
|
2020/1860
|
|
Departure angle(°)
|
10
|
Front/rear hang(mm)
|
1210/2320
|
|
Upstructure configuration
|
Tank volume(L)
|
5000
|
tank size(mm)
|
3200x1950x1500
|
|
Material
|
carbon steel, stainless steel, side thickness 6mm, bottom thickness 8mm
|
|
Asphalt Pump
|
QGB950/0.8
|
Fire Manner
|
Auto
|
|
Heating Manner
|
Thermal Oil heated by fuel
|
Speed Measuring
|
Speed Sensor
|
|
Nozzle Quantity
|
48 unit
|
Spraying Rate
|
950 L / min
|
|
Spraying width
|
4500~6000mm
|
Standard Operation
|
Human Operation,option SIEMNES intelligent control
|
Photos of 5000 Liters 4x2 Asphaltum Road Repairing Vehicle
