High Pressure Grouting Machine

Category

Leading

into the technology We provide the best equipment

Product introduction

High Pressure Grouting Machine

High pressure grouting machine is mainly used for repairing concrete crack . Polyurethane Injection grouting machine filling the slurry into the crack,then the slurry will react with the water,in order to stop the water.

Productfeatures

Environmental Protection

Good mechanical performance, low noise, and no pollution.

Portability

Small volume, light weight, convenient carrying, and simple
operation.

High efficiency

Advanced technology, time&labor saving and higher efficiency.

Security

The technology is reliable, reasonable structure, and safe use.

Pressure continues

Continuous high pressure can make effective grouting into
micro gap and micro fractures, micropores and so on.

Structure nondestructive

Grouting directly through grouting nipple installed on crack,
no clotting, no buried pipes, it's safe for structure.

Plugging with water

For a variety of crack leakage, cellular leakage, underground
water inflow, grouting can be done directly without extra
water-handling.

supporting the use of a wide range of
associated materials

Low viscosity and non-granular material like polyurethane,
epoxy resin, acrylic resin can be used.

supporting the use of a wide range of
associated materials

Low viscosity and non-granular material like polyurethane,
epoxy resin, acrylic resin can be used.

supporting the use of a wide range of
associated materials

Low viscosity and non-granular material like polyurethane,
epoxy resin, acrylic resin can be used.

ProductRange of application

Apply to subway, tunnel, culvert, sewage
treatment, and concrete crack.

Apply to concrete roof cracks, through-wall pipe,
corner of wall, and leakage of water.

Apply to basement, underground garage,
underground passage, and so on.

Apply to the reinforcement of concrete
structures, girder, pillar and plate structure cracks.

Applying to Geological drilling engineering,
it can protect and strengthen the well
wall and plugging.

Apply to cracks
in various buildings and
underground concrete engineering,
expansion joints, construction cracks
and structure cracks.

Choose us

A let you efficient work of high pressure grouting machine

Electric
drill
The
case
High pressure
pipe
Material
cup
Pressure
gauge

High pressure grouting machine is a kind of high pressure chemical grouting used in structure

grouting machine with the sophisticated & proper design easy to carry and portable, the special material of wear resistant, high-pressure perfusion & spraying machine are successfully developed by Shenglong.

High Pressure
Grouting Machine

Productclassification

JBY999 High Pressure Grouting Machine

Weight	8kg
Maximum output pressure	13500psi
Pressure of starting again	less than 7500psi
Safe range of high-pressure hose	less than 13500psi
Safe range of switch valve	less than 12000psi

SL-999 High Pressure Grouting Machine

SL-999 can generate a working pressure of 15000psi only within 10 seconds.

Portable body, weighing only 7kg, easy to carry & maintain, maximum output pressure up to 15000psi. The fault can be self-maintenance during site operation. The medicament can also be injected into small cracks and pores(larger than 0.01mm).

Net weight	7kg
Maximum output pressure	15000psi
Pressure of starting again	less than 8000psi
Safe range of high-pressure hose	less than15000psi
Safe range of switch valve	less than 15000psi
Packing size	322049CM

SL-808 High Pressure Foam Grout Machine

Net weight	8kg
Maximum output pressure	13500psi
Pressure of starting again	less than 7500psi
Safe range of high-pressure hose	less than13500psi
Safe range of switch valve	less than 10000psi
Packing size	322049CM
Power	550w/220v

SL-600 Double-liquid type High
Pressure Grouting Machine

Applicable materials
1. Double liquid-type PU Foam
Waterproofing plugging agent, insulation
material, 2. Double liquid-type quick-setting
PU/EPOXY reinforcing agent

Portable SL-500 High Pressure Injection Grouting Machine

Safe range of high-pressure pipe	less than 13500psi
Weight	7 kg
Maximum output pressure	13500psi
Pressure of starting again	less than 7500psi
Safe range of switch valve	ess than 10000psi
Drill	1 set
High pressure hose	1 pc 5M
Rubber pad	10 pcs
Seal set	1 set
repairing kit	1 set
Zerk	1 pc
Material cup	1 set
