Introduction of Z-20W Tunnel Rock Shovel Loader
Z-20W Tunnel Rocker Shovel Loader is used to load the rock, ore when the explosive blows up the big rock or ore.
Loading materials: gold, non-ferrous metal, black metal, nonmetal, and rock, ore, and etc. The max. diameter of the medium is 500mm. When the diameter is 250mm, the loading efficiency is best. Z-20W Rocker Shovel Loader runs on the railway track, so the wheel gauge is 600mm in normal, Inform us when the gauge is 762mm, 900mm, or others,
Parameters of Z-20W Tunnel Rocker Shovel Loader
|
Model
|
Z-17W
|
Z-17WYK
|
ZLKY20
|
Z-20W
|
Z-20WYK
|
ZLKY26
|
Z-30W
|
Z-30WYK
|
ZLKY45
|
ZQ26
|
|
Applicable roadway size W*H/m
|
1.7*2
|
1.7*2
|
2*2.2
|
2*2.2
|
2*2.2
|
2.2*2.5
|
2.2*2.5
|
2.2*2.5
|
2.2*2.5
|
2.2*2.5
|
|
Gauge
|
600//762/900mm ( customized )
|
|
Loading Capacity m3/h
|
20-30
|
30-40
|
35-45
|
30-40
|
40-50
|
50-60
|
50-60
|
60-70
|
80-100
|
50-60
|
|
Bucket volume㎡
|
0.17
|
0.17
|
0.2
|
0.2
|
0.2
|
0.26
|
0.3
|
0.3
|
0.45
|
0.26
|
|
Loading width mm
|
1700
|
1700
|
Arbitrarily
|
2000
|
2000
|
Arbitrarily
|
2400
|
2400
|
Arbitrarily
|
2700
|
|
Bucket working height mm
|
1920
|
1920
|
1920
|
2180
|
2180
|
2240
|
2240
|
2240
|
2240
|
2240
|
|
Bucket down height mm
|
1320
|
1320
|
1210
|
1360
|
1360
|
|
1360
|
1360
|
1460
|
1250
|
|
Gradeability
|
|
|
25°
|
|
|
25°
|
|
|
25°
|
|
|
Size
|
L mm
|
2120
|
2120
|
2287
|
2480
|
2480
|
|
|
2620
|
2660
|
2400
|
|
|
W mm
|
1130
|
1130
|
1372
|
1380
|
1380
|
|
1380
|
1380
|
1520
|
1090-1380
|
|
|
H mm
|
1200
|
1200
|
1415
|
1460
|
1460
|
|
1545
|
1650
|
1650
|
1500
|
|
Travel motor power kw
|
10.5
|
10.5
|
Hydraulic Motor 5000N/ 2units
|
10.5
|
10.5
|
Hydraulic Motor 5000N/ 2units
|
13
|
13
|
Hydraulic Motor 5000N/ 2units
|
8.83
|
|
Bucket motor power kw
|
10.5
|
10.5
|
13
|
13
|
13
|
13
|
15
|
15
|
15
|
14.71
|
|
Hydraulic motor power
|
|
1.5
|
7.5
|
|
1.5
|
7.5
|
|
2.2
|
11
|
|
|
Weight kg
|
3200
|
3300
|
3700
|
3750
|
3800
|
3900
|
4500
|
4500
|
4800
|
2700
|
|
Z- Rock loader; W-No tangled rope; YK-remote control; L-Crawler type; ZLKY-Hydraulic remote control crawler rock loader
|
Photo of Z-20W Tunnel Rock Shovel Loader
