Introduction of Full Automatic Mortar Spraying Machine
Full Automatic Cement Mortar Spraying Machine for wall
The features of Spraying machine:
1. High efficiency, 800 sq / day (thickness1.5cm)
2. Good quality,high bonding, solid and strong, avoid the phenomenon of hollowing and rework.
3. Save money. A machine with three workers, can do ten workers job (plus 10 hours work)
Mortar spraying machine is mainly used for building the mortar products internal and external wall, cement mortar powder coating and outside wall thermal insulation material mortar spraying, refractory material spraying.
Main Parameter of Full Automatic Mortar Spraying Machine
Rated Output
|
6-85 L/min
|
Rated Working Pressure
|
3 MPa
|
Total Power
|
8.5Kw
|
Main Electric Motor
|
3Phase,380volt,5.5 Kw
|
Rev.of Rotor
|
380 RPM
|
Rated Air Output
|
250L/min
|
Water Pump Rated Output
|
700L/h
|
Max.Conveying Dist.
|
50m
|
Hopper Capacity
|
120L
|
Loading Height
|
1000mm
|
Conveying Hose ID.
|
25/32mm
|
Air Hose ID.
|
13mm
|
Overall Dimension(LxWxH)
|
1240*680*1550mm
|
Weight
|
265kg
|
Images of Full Automatic Mortar Spraying Machine
B/L of The History Trading
