Introduction Of EBZ200 Coal Mine Roadheader
The machine adpots three dimensional design and the key spare parts are famous international brand products to ensure reliable performance. The center of gravity preposition design is benefit for stable operation after connecting the belt stage loader. It is a kind of cantilever type partly section roadheader, and suitable for the tunneling when the drift section is about 9-25 m2or semi-coal road tunneling. It can also be used in building railway, highway and water conservancy project.
Parameters Of EBZ200 Coal Mine Roadheader
|
Max cutting height
|
4.5m
|
|
Max positioning cutting width
|
5.7m
|
|
Tunneling section form
|
Random
|
|
Economic cutting section
|
9-25m2
|
|
grade ability
|
±16°
|
|
One way cutting coal rock compression
|
≤80MPa
|
|
Dimension (L*W*H)
|
9.1x2.55x1.7m
|
|
Production capacity
|
4m3/min
|
|
Ground clearance
|
250mm
|
|
Dinting of the Cut Head
|
150mm
|
|
Installed power
|
290kw
|
|
Total weight
|
60t
|
|
Cutter head size ( dia*width)
|
920x900
|
|
Cutting head Rotating speed
|
47.5/23.7r/min
|
|
Cutter pick form
|
pickaxe
|
|
Cutter pick quantity
|
39units
|
|
Cutting motor rated power
|
200kw
|
|
Loading capacity
|
240m3/h
|
|
Loading motor rated pressure
|
16MPa
|
|
Conveyor motor rated pressure
|
16MPa
|
|
Spade Board Width
|
3.2m
|
|
Planer gear speed
|
34r/min
|
|
Conveyor form
|
double-strand scraping plate
|
|
Walking speed
|
0-7 m/min
|
|
Ground pressure
|
0.14MPa
|
|
Crawler(caterpillar) width
|
600mm
|
|
Brake system
|
friction clutch
|
|
Pump power
|
90KW
|
|
Rated pressure
|
18 MPa
|
|
Fuel tank capacity
|
600L
|
|
Outer water spray working pressure
|
≤1.5MPa
|
|
Supply voltage
|
AC1140V/660V
|
|
Gross power
|
305KW
|
|
Operation box protection type
|
Explosion proof
|
Pictures Of EBZ200 Coal Mine Roadheader
