Product Introduction
Steel shot:S70,S110,S170,S230,S280,S330,S390,S460,S550,S660,S780,S930
Steel grits:G10,G12,G14,G16,G18,G25,G40,G50,G80,G120
Cut wire shot:1.0mm,1.5mm,2.0mm,2.5mm
And Stainless steel shot, Copper shot, Zinc shot, Aluminium shot etc.
Operative Standards:
GB/T18838.3-2008 Steel Shot and Steel Grit
SFSA20-66Cast Steel Abrasive
SAE J827 Cast Steel Shot, SAE J1993 High Carbon Steel Grit,
YB/T5149-1993 Cast Steel Shot,
YB/T5150-1993 Cast Steel Grit,
ISO11124-3 High Carbon Cast Steel Shot and Grit
Main Parameter
|
Products
|
Steel Shot
|
|
Chemical
Composition
|
C
|
0.70~1.20%
|
|
Mn
|
0.35~1.20%
|
|
Si
|
0.40~1.20%
|
|
S
|
≤0.05%
|
|
P
|
≤0.05%
|
|
Microhardness
|
Normal:40~50HRC (377~509HV)
|
|
Special:52~56HRC (543~620HV)
|
|
Special:56~60HRC (620~713HV)
|
|
Hardness Deviation
|
Max Deviation ±3.0HRC
|
|
Microstructure
|
Tempered Martensite or Sorbite
|
|
Density
|
7.2g/cm3
|
