Main Characteristics of Full Automatic Water Hyacinth Collecting Ship
1.The ship is controlled by two paddle wheels and with single bottom, single deck, full welded structure for transverse fram sty.
2.It includes the function of volume reduction, temporary storage and automatic unloading There is collecting wheel and cutter assembled in the front collecting cabin, and at the end of this cabin, there is one primary crusher driven by electric motor.
3. The middle storage cabin and rear conveying cabin can work continuously All the collection, salvage, crushing, volume reduction, storage and unloading process can achieve full automation. Front, middle and rear cabin adopt high strengthen nylon connector, in order to ensure water hyacinth collecting efficiency.
4. The maximum water hyacinth storage capacity is 15t. When it is fully loaded, the collected materials can be conveyed into barge with 3. 5m height or river bank directly. The water tank in the middle and rear cabins can prevent sewage overflow deck.
Technical Parameters of Full Automatic Water Hyacinth Collecting Ship
|
TotalWidth
|
4.0 m
|
|
Total Depth
|
2.8 m
|
|
Collecting Width
|
1.6 m
|
|
CollectingDepth
|
1.2 m
|
|
Driven Method
|
Hydraulic motor
|
|
Chain Width
|
1.0 m
|
Photos of Full Automatic Water Hyacinth Collecting Ship
