Main Characteristics of Full Automatic Aquatic Weed Harvester Main Characteristics
1.The full automatic aquatic weed harvester is used to clean the aquatic weed, water hyacinth, reed, floating garbage etc.
2. The full automatic aquatic weed harvester is one of engine, propelled by two paddle wheels with hydraulic system. It's fully automatic aquatic weed harvester. It is equipped with horizontal cutter under the front collecting conveyor, and also with anti-crash protection device to protect cutter motor, and with rotary cutting device at both sides of the collecting cabin.
3. The collecting cabin could move up and down by the hydraulic lifting system. It will be adjusted according to the collecting depth. Front collecting cabin, middle collecting cabin and rear collecting cabin are all conveyed by stainless steel conveyor belt.
4. It can be remotely controlled in the operation cabin including the navigation, collecting water weed, collecting floating trash and unloading job.
5. All the gathering, collecting, draining, and unloading work are fully automatic. The efficiency is very high, which is tens times of man power.
Technical Parameters of Full Automatic Aquatic Weed Harvester
|
Total Width
|
4.5 m
|
|
Total Depth
|
5.0 m
|
|
Collecting Width
|
23.2 m
|
|
Full loaded draft
|
≤0.7m
|
|
Empty Loaded Draft
|
≤0.5m
|
|
Loading Capacity
|
≥10m3
|
|
Driven Method
|
Paddle Wheel
|
|
Cruising Ability
|
24h
|
|
Engine Power
|
50 kw
|
Photos of Full Automatic Aquatic Weed Harvester
