COAL CUTTER
The coal cutter is light in weight and manufactured according to the standard of explosion-proof electrical appliances for mining. It is suitable for the construction operations of open-pit coal mines, sulfur mines, and gypsum mines.
COAL CUTTER
PRODUCT DESCRIPTION
The coal cutter is suitable for small and medium-sized coal mines, slow-thinning thin coal seams in underground mines, and extremely thin composite coal seams. The working face of the coal mining face can be used to cut the bottom groove and the top groove, so that the coal can be cut out.
CHINA COAL TRUSTWORTHY
COAL CUTTER
FACTORY DIRECT SALES
QUALITY ASSURANCE
QUALITY ASSURANCE
COAL CUTTER
SCOPE OF APPLICATION
Coal cutter is mainly suitable for cutting coal seams, rocks, concrete, reinforced concrete, pipes, masonry. Is a good partner for your work.
COAL CUTTER
PRODUCT FEATURES
SMALL SIZE AND FLEXIBLE OPERATION
COAL CUTTER
The coal cutter has a good appearance, small size, and the product weight is about 200 kg lighter than similar products. It is flexible in operation and convenient to carry, which is conducive to improving work efficiency and saving costs. Suitable for use in smaller projects.
DOUBLE GEARS WORK TOGETHER
The coal cutter has two gears, high speed and low speed. It can cut coal seams at low speed, high-speed no-load traction or release rope, and is equipped with an interlocking device, so it can be automatically separated to avoid sintering of the friction plate; The two gears work together to improve work efficiency.
COAL CUTTER
DOUBLE GEARS WORK TOGETHER
AVOID FRICTION SINTERING
SAVE TIME AND ENERGY
SIMPLE AND QUICK MAINTENANCE
COAL CUTTER
Coal cutter, the internal structure of the box body assembly assembly disassembly, convenient downhole maintenance, timely repair processing on site, convenient and fast, saving time and manpower and material resources for out-of-well maintenance
DOUBLE GEARS WORK TOGETHER
Coal cutter, gear and gear shaft are made of excellent steel and special heat treatment; it has high strength, long life, high temperature resistance and long working duration.
COAL CUTTER
01:SPECIALLY MADE FROM YOUGANG
02:HIGH TEMPERATURE RESISTANCE
03:HIGH STRENGTH
04:LONG WORK TIME
COAL CUTTER
TECHNICAL PARAMETERS
TECHNICAL PARAMETERS OF COAL CUTTER
Coal cutter adjustment mode Manual, pulsating
stepless speed adjustment
Traction method: traction in steel wire rope |
Motor model: YBK2—160L-4 |
Traction speed: 0 ~ 920mm / min |
Traction speed: 0 ~ 920mm / min |
Groove depth: 800 ~ 900 mm |
Rated voltage: 380V / 660V |
Chain cutting linear speed: 1900mm / s |
Dimensions: 1800 × 390 × 280mm |
Rope drum capacity: 20000mm |
Wire rope specifications: 6 × 37 (Φ10.5mm) |
Traction: 15.33KN |
Machine weight: 750 ± 2kg |
Traction power: 5KW |
Cutting power: 10KW |
Cooling method: water cooling |
No-load lowering speed: 4018mm / min |
Cooling method: Cooling in spiral water channel |
Working method: back and forth along the coal |
Dustproof method: Dustproof in the coal |
wall, work left and right |
interception section of cooling water |
Lubrication method: continuous pressureless |
lubrication |
|
