JH PROP PULLING WINCH
Compact structure
Running smoothly
Safe and reliable
JH PROP PULLING WINCH
Explosion-proof JH Prop Pulling Winch is mainly for underground prop pulling, transportation, zplacing ground anchor,and chute shifting.
PHYSICALMANUFACTURER
COMPACTSTRUCTURE
RUNNINGSMOOTHLY
HIGH WORKINGEFFICIENCY
JH series prop pulling winch adopted spherical worm gear pair drive, compact structure, are symmetrically and rectangle arranged with the sledge-shaped chassis, smooth and flexible for underground self-moving.
JH PROP PULLING WINCH
| Model Parameter | Jh-5 | Jh-8 | Jh-14 | Jh-20 | Jh-30 | |
| Steel wire ropeaverage static tension (KN) | 50 | 80 | 140 | 200 | 300 | |
| Steel wire rope (m/s)average speed | 0.17 | 0.12 | 0.115 | 0.118 | 0.13 | |
| Drum | Diameter* width (mm) | 276*372 | 280*230 | 400*317 | 430*530 | 550*560 |
| Steel wirerope | Rope capacity (m) | 80 | 100 | 130 | 170 | 220 |
| Diameter | 15.5 | 17 | 21.5 | 24.5 | 30 | |
| Construction | 6*19 | 6*19 | 6*19 | 6*19 | 6*19 | |
| Nominal extension strength (Mpa) | 1550 | 1550 | 1550 | 1550 | 1570 | |
| Explosion proof motor | Model | ybj7.5-4 | ybk2-160m-6 | ybk2-200l1-6 | ybk2-200l2-6 | ybk2-280s-4 |
| Power (KW) | 7.5 | 7.5 | 18.5 | 22 | 45 | |
| Voltage (V) | 380/660 | 380/660 | 380/660 | 380/660 | 380/660 | |
| Rotate speed (r/min) | 1450 | 970 | 970 | 970 | 980 | |
| Overall sizelength* width* height | 1450*512*515 | 1550*530*570 | 1955*680*815 | 2560*968*797 | 3300*1077*1034 | |
| Winch weight (including motor) | 620 | 650 | 1350 | 2600 | 4460 | |
JH PROP PULLING WINCH
Low center of gravity of winch
Easy to install
Has many uses
The prop pulling winch should be at an ambient temperature of -10℃~+40℃, the relative ambient temperature should not exceed 95% (+25℃), and the methane, coal seam, hydrogen sulfide, carbon dioxide, etc. in the surrounding air should not exceed the requirements of the "Safety Regulations for Coal Mines" In mines with the required safety content, the working system is low-speed and heavy-duty discontinuous.
JH PROP PULLING WINCH
The prop pulling winch is mainly composed of five parts: electric motor, helical gear, turbine box part, drum and base.
JH PROP PULLING WINCH
JH PROP PULLING WINCH
Shandong China Coal Industrial & Mining Supplies Group Co.,Ltd (hereinafter referred to as China Coal) is a group company, which is a collection of e-commerce, machinery manufacturing, software, research and development, modern logistics of large diversified industrial group.
We have a high-tech intelligent manufacturing workshop,From raw material selection to finished products, we strictly control every production process and quality,Quality inspection to ensure product safety and reliable quality!
