Introduction Of Runway Sweeper Truck for Road Sweeper
Road sweeping, road flushing, multi-angle slush flushing, separation zone cleaning, freeway guard rail flushing,spraying, moistening and dust containing, high pressure water gun for car cleaning/low flat flushing with strong water flow, road sprinkling and flower watering from both sides and so on.
Pneumatic conveying system with digestion and absorption of foreign advanced technology and efficient sweepers dedicated fans and can auto-leveling with the road the whole floating nozzle. 5.Sweeper combined with trochar disc, it can work excellently and can automotically choose work type according to waste condition on the ground and speed of the truck. ;
Parameter Of Runway Sweeper Truck for Road Sweeper
|
Driving Type
|
4*2,left hand drive,
|
|
Weights
|
|
Rated payload weight(kg)
|
100
|
|
Curb weight(kg)
|
1645
|
|
Axle loading9(kg)
|
670/1110
|
|
Dimensions
|
|
Wheelbase(mm)
|
2500
|
|
Overall Dimension(mm)
|
4020*1700*1980
|
|
Max speed(km/h)
|
98
|
|
Engine
|
|
Engine model
|
JL465QB
|
|
Engine type
|
Petrol Engine, Euro III
|
|
No. of cylinders
|
straight-4 cylinders,
|
|
Displacement(L)
|
1.012 L
|
|
Max. output (kw)
|
39kw
|
|
Drive Line
|
|
Transmission
|
5 forwards,1 reverse gear, manual operation
|
|
Cab
|
|
Air container
|
Optional
|
|
Standard configuration
|
Sound,,
|
|
Tire specification
|
|
Tire specification
|
165/70R13LT,165/70R1379T
|
|
Max cleaning width (mm)
|
2000
|
|
Cleaning efficiency (PM 10)
|
>90%
|
|
Max cleaning speed (km/h)
|
3-10
|
|
Max suction granularity (mm)
|
50
|
|
Water tank capacity (M3)
|
1.0
|
|
Garbage tank capacity (L)
|
600
|
|
suction diameter
|
50
|
Photos Of Runway Sweeper Truck for Road Sweeper
