Steel Bar Cutting Machine Introduction
1. GQ50 steel bar cutting adopts enclosed
housing, lubricate system, dual-mass flywheel and with clutch structure.
2. It works with high efficiency and safety, which is easy to operate and maintain, light in weight and energy saving.
3. Double mass flywheel, which assure strong
enough power for cutting.
Features
1. It is highly structured with reinforced
body, small size and reliable quality.
2. It applies the gear splash lubrication
system which is closed case design.
3. If fill enough lubricant oil of 8 or
10kg, it can work continuously for more than three months .
4. Energy saving , because of the
improvement of lubrication and the adoption of rolling bearing at the end of
gear axis, the resistance is small. Comparing with the other similar products, our
machines can save on third power with the same loading, equipped with rolling
wheels, which enables the machine to be movable .
5. This machine adopts high-rigid knife
block and linkage, high-speed machine of national standard, it has reliable
quality and long life.
Steel Bar Cutting Machine Main Parameter
|
Model
|
GQ50
|
|
Cutting diameter
|
Round steel :6-50mm
|
|
Class of reinforced
steel bar :6-40mm
|
|
Flat steel :80*15mm
|
|
Angle steel : 63*63mm
|
|
Square steel :40*40mm
|
|
Cutting frequency :
|
28times/min
|
|
Motor power
|
4kw
|
|
Voltage
|
380V/50HZ
|
|
Dimension
|
1370*550*880mm
|
Steel Bar Cutting Machine Figure Photos
B/L of Steel Bar Cutting Machine Trading
